Rosin Press - KWAD
KWÄD™ Rosin Press
Key Features
Fully integrated turnkey pressing system
High-force electric hydraulic operation (up to 10,000 PSI)
Dual heated platen system for consistent extraction
Enclosed safety design with emergency stop (E-Stop)
Compact, heavy-duty steel construction
Mobile workstation with adjustable working height
Engineered for repeatability, efficiency, and high yield output
Technical Specifications
Power (Press): 110–120V / 60Hz | 13A (20A recommended)
Power (Hydraulic Pump): 110–120V / 60Hz | 9A (20A recommended)
Dimensions (Press): 15" L x 15" W x 25" H
Weight (Press): 285 lbs
Hydraulic Capacity: Up to 10,000 PSI
Patent: U.S. Patent No. 11,511,465
What’s Included
KWÄD™ Rosin Press (fully assembled)
Electric Hydraulic Pump (mounted configuration)
High-pressure hydraulic hoses & fittings
Industrial Hydraulic Lift Cart (mobile scissor lift table)
Adjustable height
Locking caster wheels
Technical Specifications
Precision-engineered for professional extraction
Built Different. Built Better.
Made in the USA
Designed, engineered and assembled in Las Vegas, Nevada with the highest quality components.
Precision Engineering
Every press is calibrated and tested to deliver consistent, repeatable results batch after batch.
Lifetime Warranty
We stand behind our machines. Full lifetime coverage on all structural components and heating elements.
Dedicated Support
Our extraction experts are available 7 days a week to help you get the most from your investment.
The KWÄD rosin press is a multi-bag rosin pressing machine. PRO & PRO KIT is equipped with Automated F.C.T Automation Software by Access Rosin® as the FEEL is equipped with PID controllers with fuzzy logic. The touch screen automation carries 8 total stage with a finish stage to complete a full press on the first attempt. Store up-to 20 recipe storage. Any model provides unparalleled pressure controllability ranging from 0psi-2500psi delivering adequate pounds per square inch for optimal pressing results.
The KWÄD has a unique 12" x 12" heat plate which the shape and size creates an innovative approach to scaling rosin production. The total surface area is 135" square, enabling operators to produce rosin in bulk quantities without jeopardizing quality at scale. The collection cavity of the KWÄD measures 5.250"(w) x 17"(d) x 12" (h) and is equipped with post melt separation capability, ensuring that the rosin produced is of the highest quality.
Specifications
| Color | Black or Red or Blue or Gold or Green or Purple or Aluminum (Polish) |
| Hydraulic Pump | E-Hydraulic Pump (Double-Acting) or Hand Pump (Double-Acting) |
| Hydraulic Stand | System Mounted to Cart or No Cart |
| Power | 110v/120v 60hz |
| Current | 13.5 Amps |
| Cylinder Pressure | 0-10,000 psi |
| Heat Plate | 12” x 12” |
| Flow Port | 3“ x 3” |
| Capacity Per Bag | Up-to 100g |
| Capacity Per Press | 20-400g |
| Size | 18" (l) x 18" (w) x 31.5" (h) |
| Weight | 426lbs |
