Access Rosin Dual Press
Twin 6×10" platens with four independent heat zones, so you can press two materials at two temperatures at once. Double your throughput without doubling floor space or operators.
DUAL Configurator
Two Presses in One Footprint
Independent zones let you run different materials, grades, or temperatures side by side.
Dual-Zone Independence
Press washed material at 170°F on one platen while pressing botanical material at 200°F on the other — zero thermal cross-contamination.
Double the Throughput
Twin 6×10" platens, 25 tons each (50 tons combined), let one operator run two batches at once.
4-Zone PID Control
Four independent controllers with fuzzy-logic ±1°F accuracy keep every quadrant on-temp.
Manual Hydraulic Reliability
Tactile hydraulic control with direct pressure feedback. Optional BVA P352 or P1000 pumps.
Seven Finishes
Black, Red, Blue, Gold, Green, Purple, and Polished Aluminum chassis options.
Built to Last
Powder-coated steel H-frame and precision-milled 6061-T6 aluminum platens.
Technical Specifications
| Configuration | Dual-plate parallel processing |
|---|---|
| Plate Dimensions | Two 6×10" (60 sq in each) |
| Total Force | 50 tons (100,000 lbs) combined — 25 tons per plate |
| Temperature Zones | 4 independent PID controllers |
| Temp Accuracy | ±1°F fuzzy-logic control |
| Plate Material | Precision-milled 6061-T6 aluminum |
| Hydraulic Pump | Optional: BVA P352 or BVA P1000 |
| Dimensions | 42" W × 24" D × 48" H |
| Weight | 220 lbs |
| Power | 220V / 30A, dual phase |
| Warranty | 1-year (frame & platens), 2-year (electronics) |
Run Two Batches at Once
See how parallel processing doubles output for multi-strain operations.
Request a Custom Quote
